The Male Thread Ball Bibcock combines an isolation valve and directed outlet in one compact body. Turning the lever rotates a bored ball through a quarter turn, aligning or blocking the flow passage without repeated stem travel. The bent outlet directs flow downward and the hose connection supports washdown or other local discharge tasks. Its main technical highlight is the simple quarter-turn operating path, which gives a clear open or closed position. The selected inlet thread must match the fixed supply line, while space around the valve should allow full handle movement.
Components
Valve body and cap - contain the internal flow path and threaded inlet.
Ball, stem, and lever - provide the quarter-turn opening and closing action.
Seats, packing, O-rings, and gaskets - seal moving and joined interfaces.
Bent outlet and hose connection - direct fluid toward the discharge point.
Handle sleeve - provides a defined grip area for manual operation.
Product Parameters
|
Item |
Specification |
|
Product Code |
SC201W |
|
Pressure Rating |
200 PSI / PN16 |
|
Construction |
Investment casting |
|
Sizes |
1/2 in., 3/4 in., 1 in. |
|
Thread Standards |
ASME B1.20.1; BS21; DIN 2999/259; ISO 228-1; JIS B0203; ISO 7-1 |
|
Inspection |
API 598; EN 12266 |
|
Approval |
PED 97/23/EC (CE0035) |
|
Body / Cap |
CF8 / CF8M |
|
Ball |
304 / 316 stainless steel |
|
Ball Seat / Packing |
PTFE |
|
Stem / Handle |
304 stainless steel |
|
O-Ring / Gaskets |
NBR |
|
Hose Connection |
CF8 / CF8M |
|
Handle Sleeve |
PVC |
|
Dimensions D/H/W/L |
1/2 in.: 9/91/92/138 mm; 3/4 in.: 15/102/92/145 mm; 1 in.: 20/116/92/158 mm |
Main Applications
Utility water outlets in workshops, wash areas, service rooms, and garden installations. The Male Thread Ball Bibcock can be considered for these points when the inlet thread, hose connection, media, and installation clearance match the layout.
Equipment skids that need a compact local shutoff with downward discharge.
Rinsing and washdown points connected to a compatible flexible hose.
General compatible fluid service where a lever-operated outlet valve is specified.
FAQ
Q: How is flow opened or closed?
A: The lever rotates the internal ball through a quarter turn. For a Male Thread Ball Bibcock, confirm nominal size, thread form, fluid compatibility, and handle clearance before installation.
Q: What connection arrangement is provided?
A: The valve has a male threaded inlet and a hose-style discharge connection.
Q: What should be confirmed before installation?
A: Check nominal size, thread standard, media compatibility, flow direction, and handle clearance.
